MxPro5 Single Loop Intelligent Fire Control Panel (MX-5101)

Talk to our specialists

Description

The MX-5101 control panel is supplied with a single loop driver card, 2 onboard sounder circuits, 20 programmable zonal LEDs with slide-in labels, and 25 system LEDs for information purposes. There are also 4 programmable function buttons with LED indication for confirmation of operation.

Additional information

Further Description

The control panel consists of the latest dual flash-based microprocessor technology combined with a high resolution, high contrast, graphical LCD display and tactile keypad providing a simple select and click programming aid for engineer configuration and end-user operation.
Powerful cause-and-effect programming and enhanced trace diagnostics make the panel suitable for a wide range of site applications from small to large complex multi-area systems.
Fully programmable onsite via the onboard alphanumeric keypad, or PC-NeT configuration software.

PC Software

An extensive suite of user-friendly Windows-based PC software programs has been developed to enhance your experience when using MxPro5 series fire panels. The suite incorporates a number of different programmes which include configuration, service, logo and virtual panel tools to allow the flexibility of the equipment to be fully explored.

Network

Simply adding a network card allows the panel to communicate with any other MxPro5 fire panel, remote terminal, or network peripheral, such as ipGateway™, BMS or graphical interface. The network operates as a true peer-to-peer system and can be configured in a fault tolerant loop or radial format.

Features

• 20 programmable zonal / 25 System LEDs
• Apollo, Hochiki & Nittan Evolution protocol support
• Graphical LCD user interface and support for up to 200 fire zones by default allowing full EN54 compliance without additional hardware
• Dedicated USB & RS232 Serial Port for direct PC or modem connection
• Installer friendly Auto-learn, Loop Detection and Onboard Scope facility
• Graphical display configurable for virtually any language
• Robust removable equipment chassis with plug-in connectors for simple fixing and cable termination
• Integral P-Bus for system expansion via available option cards
• Ad-NeT peer-to-peer network with up to 2000 zones
• Programmable push buttons
• Rack-mount options
• Multiple languages
• Global compliance
• Fully networkable
• 3-year warranty
• Fully programmable
• Installer’s logo application

100-2039V

EURV-SBR-IP65 Intelligent AV Wall Mounted Sounder Beacon

Available in red (100-2039V) or white (100-2039VW). The unit has a built in microphone which allows the unit to indicate a fault should the sounder not operate when activated or tested.

EVAC-RES-ISO

Dual Residential Isolator Module

The dual residential isolator module is designed to provide short circuit isolation features for Euro-VAC loops carrying Eurotech devices. It operates with Euro-VAC control panel protocol which provides for high rates of information exchange in combination with particular features that ensure fast and secure responses.

EVAC-FLR-ISO

Single Floor Isolator Module

The single floor isolator module is designed to provide short circuit isolation features for Euro-VAC loops carrying Eurotech devices. It operates with Euro-VAC control panel protocol which provides for high rates of information exchange in combination with particular features that ensure fast and secure responses.

100-2034V

EURV-OM-RM Single Relay Output Mini Module

The single output module (100-2034V) is loop-powered, designed around a fully digital protocol and provides a fast and secure response. The output channel is monitored and detects open and short circuit conditions. Connections are made using plug-in terminal blocks.
